"The Spider" Internal Pipe Fit-Up Clamps
"The Spider" Internal Pipe Fit-Up Clamps
Regular price
$484.20
Sale price
$484.20
Regular price
$538.00
Shipping calculated at checkout.
Available in stock
Precision Alignment for Pipe Welding.
“The Spider” Internal Fit-Up Clamp ensures precise alignment for welding pipe to flange, or pipe to pipe.
-
CNC Machined for Precise Alignment: CNC machining ensures smooth adjustments and accurate alignment, making it easy to achieve optimal positioning for every weld.
- Stainless Steel Contact Points: All contact points are made from durable stainless steel, offering superior resistance to corrosion and wear.
- Dual Locating Legs Adjustment: Two knobs for independent adjustment of the front and rear sections. Expand one set of Locating Legs to anchor securely within the pipe, while the second set of legs adjusts to perfectly align the pipe or flange.
- Versatile Fit: Accommodates a variety of pipe diameters from 4" to 8" (8" to 12"), weighing under 20 lbs, providing flexibility for various welding projects.
-
Estimated delivery: Feb 06 - Feb 10
Couldn't load pickup availability
California Prop 65 - This product may contain chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm. For more info: www.P65Warnings.ca.gov
Manual Download
Manual Download
Spec Download
Spec Download
CAD Drawings Download
CAD Drawings Download
| Part No. | Flange (in) | Internal Diameter (in) | Flange Weight Capacity (lb) | OAL (in) | Weight (lb) |
|---|---|---|---|---|---|
| CSA480 | 4 ~ 8 | Ø3.26～Ø8.15 | Less than 20 | 15.6 | 5.5 |
| CSA812 | 8 ~ 12 | Ø6.7～Ø12.7 | Less than 55 | 20.2 | 18 |
