5x3 max nitrided table, slotless, full table
5x3 max standard finish table, slotless, full table
5x3 max nitrided table, slotless, full table
5x3 max standard finish table, slotless, full table
Max 5' × 3' (60" x 36") Tables, 5/8" System (Older Model)
Max 5' × 3' (60" x 36") Tables, 5/8" System (Older Model)
Max 5' × 3' (60" x 36") Tables, 5/8" System (Older Model)
Max 5' × 3' (60" x 36") Tables, 5/8" System (Older Model)
Max 5' × 3' (60" x 36") Tables, 5/8" System (Older Model)
Max 5' × 3' (60" x 36") Tables, 5/8" System (Older Model)
Save 10%

Max 5' × 3' (60" x 36") Tables, 5/8" System (Older Model)

Max 5' × 3' (60" x 36") Tables, 5/8" System (Older Model)

Patented

SKU: TMA56036F-OLD

All BuildPro® Tables are constructed from 5/8" thick steel plate, with Ø5/8" CNC machined and holes chamfered in a 2" grid pattern.

Actual Table Surface Dimension: 60" x 36"
Tabletop Side Height: 6-1/4"

* All load capacities are calculated based on static load.

* Optional Leg Brace Assembly TMLB60 is suggested.

U.S. PAT. 8065967
Finish: Standard
Legs: 6x Heavy Duty 30-1/4" Legs
$3,470 USD
$3,470 USD $3,855 USD
Shipping calculated at checkout.
  • Eligible for Return Within 30 Days.
  • One Year Limited Warranty

California Prop 65 - This product may contain chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm. For more info: www.P65Warnings.ca.gov

Manual Download

Table Setup Instructions

Reversible Plate Instructions

Use with 6x Heavy Duty Legs

Part No. (Standard Finish) Part No. (Nitrided Finish) Use with Leg Table Surface Height (in) Gross Weight (lb)
TMA56036F TMQA56036F TML3130 36-1/2 734
TMB56036F TMQB56036F TML2530 30-1/2 722

Use with 6x adjustable legs - adjustable at 1" increments

Part No. (Standard Finish) Part No. (Nitrided Finish) Use with Leg Table Surface Height (in) Gross Weight (lb)
TMR56036F TMQR56036F TMLR30 28-1/2 ~ 38-1/2 755

Use with 6x adjustable legs with mobility caster

Part No. (Standard Finish) Part No. (Nitrided Finish) Use with Leg Table Surface Height (in) Gross Weight (lb)
TMRC56036F TMQRC56036F TMLC30 33-1/4 ~ 43-1/4 789
View this table in your shop

* All MAX TABLES ARE PATENTED: U.S. PAT. 8065967

Our single-sided heavy-duty tables feature boreholes on the top surface and feature patented self-locating and reversible table top plates. Maximum Table Surface, Maximum Capacity. Utilize the additional holes (33% more than slotted tables) for clamping at multiple points.

Available in standard and nitrided tabletop finishes.

Reversible Self-Locating Table Plates

Patented Bushing design allows you to remove, re-position, re-align, and reverse the table plates!

Tabletop Side Height

6-1/4″ for both MAX and MAX Slotted tables

Table Accuracy

Table flatness: ±0.005 per 24″ x 24″

Hole spacing: 2.000″ ±0.001

Hole diameter: 0.625″ +.002/-.000

Plate thickness: 0.630″ ±0.004

Standard (plain) / Nitrided Finish

Choose from standard finish (medium carbon steel) or Nitrided (heat-treating) finish.
