Part No. Name Length (mm) Width (mm) Height (mm) Thickness (mm) Weight (kg)
T28-13028L HD Cast Square 300 - Left 280 95 300 approx. 27 12.9
T28-13028R HD Cast Square 300 - Right 280 95 300 approx. 27 12.9
T28-16038L HD Square 600 - Left 375 95 600 approx. 27 22.5
T28-16038R HD Square 600 - Right 375 95 600 approx. 27 22.5
T28-18038L HD Square 800 - Left 375 95 800 approx. 27 27.0
T28-18038R HD Square 800 - Right 375 95 800 approx. 27 27.0

If you need some documents but not able to find them here, please fill out the form below. Our engineering team will get back to you shortly.

Downloads

Spec Drawing

Manual

CAD

T28-13028L - STEP

T28-13028R - STEP

T28-16038L - STEP

T28-16038R - STEP

T28-18038L - STEP

T28-18038R - STEP
