12-pc Clamping Kit w/ Tool Pouch, Scout Series (TSB-A)
- 12 tools Clamps, pliers, stops, V-blocks
- 5/8" holes Drops into any 5/8" table
- 300 lb Inserta Clamp pressure
- 12" × 8" Nylon zip pouch
-
Estimated delivery: Sep 25 - Sep 29
No se ha podido cargar la disponibilidad de recogida
Overview
Clamp, hold and locate, anywhere
The TSB-A is the fixturing kit built for the Scout Series. Twelve 5/8" tools in their own pouch, so a sawhorse or table you already own can clamp and locate work like a fixturing table.
Every piece has a 5/8" stud or rail, so it drops straight into the 5/8" holes on a Scout 36, Scout Tripod, Scissor Lift Sawhorse or any Strong Hand Tools 5/8" fixturing table. Clamps to push parts down, pliers to grip them, stops to locate them and V-blocks to cradle round stock.
The whole kit weighs 7.7 lb (3.5 kg) and zips into a 12" × 8" nylon pouch.
- Contents
- 12 tools2 clamps · 2 pliers · 4 stops · 4 V-blocks
- Fits
- Ø5/8" holes0.625" (16 mm) fixturing holes, any 2" grid
- Kit weight
- 7.7 lb3.5 kg, tools and pouch
- Pouch
- 12" × 8"305 × 203 mm nylon, zip top
- 16 mm version
- TSBM-Asame kit for 16 mm tables
In the kit
Four tools,
twelve pieces
Two of each clamp, four of each locator. Every piece is a standard Strong Hand Tools 5/8" fixturing tool, so every piece is also sold on its own when you want spares or more of one type.
- 2×
UDN5150
Inserta Clamp
Drop the 5/8" rail into a hole and wind the T-handle down. Clamps vertically or horizontally at any height along the rail; the arm lifts off by depressing the spring stop.
- Capacity
- 6-1/2" (165 mm)
- Throat depth
- 3-1/4" (83 mm)
- Clamping pressure
- 300 lb (136 kg)
- 2×
PTT634K
Inserta Pliers
Locking pliers on a 5/8" swivel adaptor. The rear crank sets the clamping pressure while locked, so a pre-set opening repeats part after part; the adaptor gives 1.0" (25 mm) of reach in or out.
- Capacity
- 3.3" (84 mm)
- Throat depth
- 3.4" (86 mm)
- Weight
- 1.2 lb (0.54 kg)
- 4×
T54205
Inserta Stop
A fixed fence in any hole. Butt the part against the stops, then clamp. The 5/8" hole in the top takes another stop or a V-block for taller work.
- Body
- Ø1" (25 mm)
- Height above table
- 2" (51 mm)
- Stud below
- Ø5/8" × 0.7" (18 mm)
- 4×
T54216
V-Block, 120°
Cradles round parts up to 2.5" (64 mm). Tube, pipe and bar sit in the 120° V instead of rolling on the plate. Die-cast aluminum with a 5/8" stud.
- Size
- Ø1.6" × 0.9" H
- V angle
- 120°
- Max tube
- 2.5" (64 mm)
TSB366-P
Works with
Any 5/8" hole you own
Scout 36 Sawhorse (TSB366)
This is the kit inside every Scout 36 "12pc Clamping Kit" package. Buy it on its own to fit out a Scout 36, Scout Tripod or Scissor Lift Sawhorse you already have, or to add a second set of tools to a Scout Duo.
The Scout 36 top is a 5/8"-thick nitride-coated steel plate with 5/8" holes on 2" centers, made for Inserta clamps, pins and V-blocks. Sawhorse sold separately.
- 36" × 6"Top plate
- Ø5/8" on 2"Hole grid
- Kit optionon every Scout 36 build
Every tool has a Ø5/8" stud or rail, so the kit is not tied to the sawhorse. It drops into any Strong Hand Tools 5/8" fixturing hole: the Scout Series, the Alpha 5/8" tables and the Rhino Cart tops.
Compare
Which Scout kit?
Four kits, one pouch. The TSB-A is the full set; the B, C and D kits are subsets of it for when you already own part of the set. Only the TSB-A includes the V-blocks.
Specifications
Every number,
every piece
Kit totals first, then each tool. Component figures are the same as on their own product pages.
| Spec | 12-pc Clamping KitTSB-A |
|---|---|
| Kit | |
| Contents | 12 tools + pouch2 Inserta Clamps, 2 Inserta Pliers, 4 stops, 4 V-blocks, 1 zip pouch |
| Hole system | Ø5/8"0.625" (16 mm) fixturing holes; 16 mm tables use the TSBM-A |
| Kit weight | 7.7 lb3.5 kg, tools and pouch |
| Pouch | 12" × 8"305 × 203 mm nylon zip pouch, TSB366-P |
| Inserta Clamp UDN5150 · 2 pcs | |
| Clamping capacity | 6-1/2"165.1 mm |
| Throat depth | 3-1/4"82.6 mm |
| Clamping pressure | 300 lb136 kg |
| Rail | 5/8" × 5/16"15.9 × 7.9 mm; T-handle screw; replacement pad XDP |
| Weight, each | 1.2 lb0.54 kg |
| Inserta Pliers PTT634K · 2 pcs | |
| Max. capacity | 3.3"83.8 mm |
| Throat depth | 3.4"86.4 mm |
| Mount | 5/8" swivel adaptor1.0" (25.4 mm) of extended reach or retraction; rear crank pressure adjustment |
| Weight, each | 1.2 lb0.54 kg |
| Inserta Stop T54205 · 4 pcs | |
| Body | Ø1" × 2" H25.4 × 50.8 mm above the table; 2.7" (69 mm) overall with the stud |
| Stud | Ø5/8" × 0.7"15.9 × 18 mm |
| Top | 5/8" stacking holetakes another stop or a V-block |
| Weight, each | 0.5 lb0.23 kg |
| V-Block T54216 · 4 pcs | |
| Size | Ø1.6" × 0.9" H40 × 22.6 mm |
| V angle | 120° |
| Max. round stock | 2.5"63.5 mm |
| Material | Die-cast aluminum5/8" stud; 3/8-16 thread |
FAQ
Questions, answered
Straight answers on fit, the Scout 36 bundles, the 16 mm version and the warranty.
- Will it fit my table?
- Yes, if the table has Ø5/8" holes. Every tool in the kit has a 5/8" stud or rail, so it drops into a Scout 36, Scout Tripod, Scissor Lift Sawhorse, Alpha 5/8" table or Rhino Cart top. For tables with 16 mm holes, order the TSBM-A instead.
- Is this the same kit that comes with the Scout 36 packages?
- Yes. The "12pc Clamping Kit" option on the Scout 36 sawhorse is this kit. If you already own a Scout 36 without it, the TSB-A is how you add it.
- What does "12-pc" count?
- The tools. 2 Inserta Clamps, 2 Inserta Pliers, 4 stops and 4 V-blocks make 12. The zip pouch comes with them but is not counted.
- Which Inserta Clamp is in the kit?
- The T-handle UDN5150, 6.5" capacity. The straight-handle (UDWN5150) and ratchet-handle (UERN5200) Inserta Clamps are sold separately if you want to mix in a different handle.
- What is the warranty?
- One year limited warranty, and the kit is eligible for return within 30 days.
